QWALL-HD
4X4 HDMI VideoWall Processor, Powerful, Compact and Easy to Use can be controlled from anywhere through web browser.
Description
- Complete hardware solution – no need for a PC
- Plug-and-play ready
- Four HDMI inputs and four HDMI outputs
- HDMI digital audio output
- Learns any EDID
- Built-in database
- Ethernet control-ready
- Multiple screen modes and picture flip functions
- Easy control and access
- HDMI 1080p
- Supports IR and RS-232
- 1920 x 1080p resolution
| VIDEO | |
|---|---|
| Video Bandwidth | Single-link 340MHz [10.2Gbps] |
| Resolution HDTV | 480i, 480p, 720i, 720p, 1080i, 1080p |
| Single Link Range | 1080p |
| Format | HDMI 1.4 |
| DVI Compliance | Single-link DVI-D 2.0 |
| HDCP Compliance | 1.0/2.0 |
| Input Interface | (4) HDMI |
| Output Interface | (4) HDMI |
| Connector | Type A [19-pin female] |
| AUDIO | |
| Format | HDMI Digital Audio |
| Frequency Response | 20Hz ~ 20KHz |
| Output Interface | 3.5 mm stereo audio |
| CONTROL | |
| Front Panel | Push Buttons with LED Indicators |
| RS-232 | DB9 (female) Via Control @ 9600 bps |
| Hot Keys | Via Keyboard |
| Remote | IR |
| Web | Web Interface |
| OTHER | |
| Power Supply | Internal 100-240 VAC |
| Dimensions | 17.0” W x 2.0” H x 10.75” D |
| Weight | 4.4 lbs |
| Approvals | UL, CE, ROHS Compliant |
| Operating Temperature | +32 to +104°F (0 to +40°C) |
| Storage Temperature | -4 to 140°F (-20 to +60°C) |
| Humidity | Up to 80% (No Condensation) |
