EWP-WA510H-WW-FIT
|
Features |
WA530X-WW |
|
Weight(excluding mounting accessories) |
1.8kg |
|
Dimensions (excluding mounting accessories) |
250 x 250 x 79.5mm |
|
Fixed port |
Two 10/100/1000M Ethernet ports /support LACP(support between both network ports for redundancy and increased capacity) One 1000M SFP port One Console port |
|
Antenna |
Built-in, directional antenna Radio 1 : 8.6dBi antenna gain @ 5G Radio 2 : 10.1dBi antenna gain @ 2.4G |
|
Operating frequencies |
802.11ac/n/a : 5.725GHz-5.850GHz; 5.47～5.725GHz; 5.15~5.35GHz 802.11b/g/n : 2.4GHz-2.483GHz |
|
Modulation |
OFDM: BPSK@6/9Mbps, QPSK@12/18Mbps, 16-QAM@24Mbps, 64-QAM@48/54Mbps MIMO-OFDM (11ac): MCS 0-9 |
|
Modulation Mode |
11b: DSS: CCK@5.5/11Mbps, DQPSK@2Mbps, DBPSK@1Mbps 11a/g: OFDM: 64QAM@48/54Mbps, 16QAM@24Mbps, QPSK@12/18Mbps, BPSK@6/9Mbps 11n: MIMO-OFDM: BPSK, QPSK, 16QAM, 64QAM 11ac: MIMO-OFDM: BPSK, QPSK, 16QAM, 64QAM, 256QAM |
|
Maximum transmit power |
2.4GHz: 18dBm 5GHz: 22dBm (Transmit power is multi-chain combined power, no antenna gain is included. The actual transmit power depends on local laws and regulations) |
|
Adjustable power |
1dBm |
|
Power Source |
802.3at PoE+ PoE Adapter(Optional) |
|
Power consumption |
≤25.5W |
|
Protection degree |
IP67 |
|
Operating temperature/storage temperature |
-40 ºC～65 ºC; -30 ºC～55ºC(recommended) /-40ºC～85ºC |
|
Operating humidity/storage humidity |
0% to 100% (non-condensing) |
|
Safety compliance |
IEC 60950-1, EN 60950-1, IEC 60950-22, EN 60950-22 |
|
EMC |
EN 301489-1, EN 301489-17, EN 55032, EN 55024, EN 60601-1-2 |
|
Radio frequency certification |
EN 300 328, EN 301 893 |
|
Health |
EN 50385 |
