2701A02K

Weight

3.2kg

Dimensions (W × D × H)

280mm x 280mm x 85mm (without mounting brackets)

Interface

1 x 100/1000M/2.5G/5G/ Multigigabit Ethernet, RJ-45, PoE input

2 x 1000M/10G optical port, SFP+

Console port

1 x Management console port (RJ-45)

PoE input

1 x 100/1000M/2.5G/5G/ Multigigabit Ethernet, 802.3bt

Local power supply

100V to 264V AC (Alternating Current)

Antenna type

External antenna (sold separately)

Integrated built-in directional antenna [1]

Built-in IoT module

BLE5.1

Frequency bands

2.400 to 2.4835GHz ISM

5.150 to 5.250GHz U-NII-1

5.250 to 5.350GHz U-NII-2A

5.470 to 5.725GHz U-NII-2C

5.725 to 5.850GHz U-NII-3/ISM

Note: The available bands and channels are dependent on the configured regulatory domain (country)

Modulation technology

802.11b: Direct-sequence spread spectrum (DSSS)

802.11a/g/n/ac: Orthogonal frequency-division multiplexing (OFDM)

802.11ax: Orthogonal frequency-division multiple access (OFDMA)

Modulation mode

11b: BPSK, QPSK, CCK

11a/g/n: BPSK, QPSK, 16QAM, 64QAM

11ac: BPSK, QPSK, 16QAM, 64QAM, 256QAM

11ax: BPSK, QPSK, 16QAM, 64QAM, 256QAM, 1024QAM

Data rates (Mbps)

802.11b: 1, 2, 5.5, 11

802.11a/g: 6, 9, 12, 18, 24, 36, 48, 54

802.11n: 6.5 to 600 (NSS = 1 to 4, HT20 to HT40)

802.11ac: 6.5 to 6,933 (MCS0 to MCS9, NSS = 1 to 8, VHT20 to VHT160)

802.11ax: 7.3 to 9,608 (MCS0 to MCS11, NSS = 1 to 8, HE20 to HE160)

Maximum transmit power

5GHz: 30 dBm

2.4GHz: 30 dBm

Note: Transmit power is multi-chain combined power, no antenna gain is included. The actual transmit power depends on local laws and regulations

Adjustable power granularity

Configurable in increments of 1dBm

Anti-theft

Security screw directly on the chassis

Installation

Wall mounting/Pole mounting, the mounting bracket is not included by default and needs to be purchased separately

Indicators (LED)

Yellow/green/blue status LEDs for different working states indicate boot loader status, association status, operating status, and fault states of the system

Temperature

Operating temperature: -40°C to +65°C

Storage temperature: –40°C to +85°C

Humidity

Operating humidity: 0% to 100% (non-condensing)

Storage humidity: 0% to 100% (non-condensing)

Protection class

IP68

Surge protection

Common Mode：6KV

Overall power consumption

34W

Safety standards

IEC/EN 62368-1

GB 4943.1

SRRC

EMC standards

EN 301 489-1

EN 301 489-3

EN 301 489-17

EN 60601-1-2

EN 55032

EN 55035

CISPR 32

CISPR 35

AS/NZS CISPR32

ICES-003 Issue 7

GB/T 9254.1

GB/T 9254.2

GB 17625.1

GB 17625.2

IEC/EN 61000-4-2

IEC/EN 61000-4-3

IEC/EN 61000-4-4

IEC/EN 61000-4-5

IEC/EN 61000-4-6

IEC/EN 61000-4-8

IEC/EN 61000-4-11

IEC/EN 61000-3-2

IEC/EN 61000-3-3

Radio standards

ETSI EN 300 328

ETSI EN 301 893

ETSI EN 300 440

FCC Part 15E

RoHS standards

DIRECTIVE 2011/65/EU

(EU) 2015/863

Health standards

EN 50385:2017

EN IEC 62311:2020

MTBF (25°C)

2557272 hours
