Weight
|
1.8kg
|
|
Dimensions (W × D × H)
|
250mm x 250mm x 79.5mm (without mounting brackets)
|
|
Interface
|
1 x 10/100/1000M Ethernet, RJ-45, PoE input
1 x 10/100/1000M Ethernet, RJ-45, PoE output
1 x 1000M optical port, SFP
|
|
Console port
|
1 x Management console port (RJ-45)
|
|
PoE input
|
1 x 10/100/1000M Ethernet, 802.3at/af
|
|
PoE output
|
1 x 10/100/1000M Ethernet, 802.3af
|
|
Local power supply
|
POE injector (sold separately)
|
|
Antenna type
|
Support built-in directional antenna (default)
Support extended external antenna
Note: Only one of the two modes (internal antenna and external antenna) can be selected.
|
|
Antenna gain
|
5GHz peak gain: 11dBi
2.4GHz peak gain: 11dBi
Note: Horizontal beamwidth (HBW): 65 degrees, Vertical beamwidth (VBW): 30 degrees
|
|
Built-in IoT module
|
BLE5.1
|
|
Frequency bands
|
2.400 to 2.4835GHz ISM
5.150 to 5.250GHz U-NII-1
5.250 to 5.350GHz U-NII-2A
5.470 to 5.725GHz U-NII-2C
5.725 to 5.850GHz U-NII-3/ISM
Note: The available bands and channels are dependent on the configured regulatory domain (country)
|
|
Modulation technology
|
802.11b: Direct-sequence spread spectrum (DSSS)
802.11a/g/n/ac: Orthogonal frequency-division multiplexing (OFDM)
802.11ax: Orthogonal frequency-division multiple access (OFDMA)
|
|
Modulation mode
|
11b: BPSK, QPSK, CCK
11a/g/n: BPSK, QPSK, 16QAM, 64QAM
11ac: BPSK, QPSK, 16QAM, 64QAM, 256QAM
11ax: BPSK, QPSK, 16QAM, 64QAM, 256QAM, 1024QAM
|
|
Data rates (Mbps)
|
802.11b: 1, 2, 5.5, 11
802.11a/g: 6, 9, 12, 18, 24, 36, 48, 54
802.11n: 6.5 to 600 (NSS = 1 to 4, HT20 to HT40)
802.11ac: 6.5 to 6,933 (MCS0 to MCS9, NSS = 1 to 8, VHT20 to VHT160)
802.11ax: 7.3 to 9,608 (MCS0 to MCS11, NSS = 1 to 8, HE20 to HE160)
|
|
Maximum transmit power
|
5GHz: 27 dBm
2.4GHz: 30 dBm
Note: Transmit power is multi-chain combined power, no antenna gain is included. The actual transmit power depends on local laws and regulations
|
|
Adjustable power granularity
|
Configurable in increments of 1dBm
|
|
Installation
|
Wall mounting/Pole mounting, the mounting bracket has been preinstalled on the back of the AP
|
|
Indicators (LED)
|
Yellow/green/blue status LEDs for different working states indicate boot loader status, association status, operating status, and fault states of the system
|
|
Temperature
|
Operating temperature: -40°C to +65°C
Storage temperature: –40°C to +70°C
Note: The value may vary depending on the installation environment.
|
|
Humidity
|
Operating humidity: 0% to 100% (non-condensing)
Storage humidity: 0% to 100% (non-condensing)
|
|
Protection class
|
IP68
Note: Even when used with external antenna
|
|
Surge protection
|
Common Mode：6KV
|
|
Overall power consumption
|
31W (including PSE)
16W (excluding PSE)
Note: Power required at the power source equipment (PSE) will depend on the cable length and other environmental issues.
|
|
Safety standards
|
IEC/EN 62368-1
GB 4943.1
SRRC
|
|
EMC standards
|
EN 301 489-1
EN 301 489-3
EN 301 489-17
EN 60601-1-2
EN 55032
EN 55035
|
|
CISPR 32
CISPR 35
AS/NZS CISPR32
ICES-003 Issue 7
GB/T 9254.1
GB/T 9254.2
GB 17625.1
GB 17625.2
|
|
IEC/EN 61000-4-2
IEC/EN 61000-4-3
IEC/EN 61000-4-4
IEC/EN 61000-4-5
IEC/EN 61000-4-6
IEC/EN 61000-4-8
IEC/EN 61000-4-11
IEC/EN 61000-3-2
IEC/EN 61000-3-3
|
|
Radio standards
|
ETSI EN 300 328
ETSI EN 301 893
ETSI EN 300 440
FCC Part 15E
|
|
RoHS standards
|
DIRECTIVE 2011/65/EU
(EU) 2015/863
|
|
Health standards
|
EN 50385:2017
EN IEC 62311:2020
|
|
MTBF (25°C)
|
875378 hours
|
