T-4240UC

Model

T-2120UC

T-2240UC

T-4120UC

T-4240UC

Output terminal

4-16Ω, 100V

Output power

2*120W

2*240W

4*120W

4*240W

Input sensitivity & impedance

INPUT1-4: 5mV-350MV±40MV/600Ω;

LINE1-2: 350mV±40MV/10KΩ unbalanced RCA connector;

EMC: 775mV/10KΩ unbalanced European connector

Output sensitivity & source impedance

CH1-2: 1000mV/470Ω unbalanced RCA connector

Tone

Bass: ±10dB at 100Hz

Treble: ±10dB at 10KHz

Frequency response

80~16KHz(+1dB,-3dB)

SNR

INPUT1-4:66dB; LINE1-2:80dB

THD

< 0.5% (at 1KHz, 1/3 rated power)

Phantom power

48V (±2V)

Protection

High temperature, overload, short circuit

Cooling

Fan forced cooling

Power consumption

370W

650W

650W

1200W

Power supply

230V/50Hz

Dimension

484x395x88mm

Weight

6.0kg

6.2kg

7.3kg

7.6kg
