MuraControl for Windows Software
Matrox MuraControl Software specifications
Specifications |
MuraControl for Windows |
| Part Number |
MURA-CTRLWF |
| Supported OS |
Windows 10 and 11 |
| Supported Video Wall Platforms |
D-Series, D-Series + IPX Capture Cards, LUMA Pro Series, LUMA Pro Series + IPX Capture Cards, Mura C4K Capture Card, and Mura DVW Appliance |
| Layout Management |
Create, save, preview, apply, lock, copy, import, export, and delete |
| Layout Scheduling |
Yes |
| Image and Text Overlay |
Create, edit, delete, apply multi-lingual unicode text overlay and marquee text, and image overlay, including control over font, colour, size, location, and speed |
| Window Management |
Create, position, rotate (any arbitrary angle), and resize Windows anywhere on the wall, including control of advanced window border color and width |
| Window Cropping |
Advanced |
| Z-Order Management |
Advanced: ability to set Z-order value of each window |
| Source Management |
Create, rename, crop, rotate, and text overlay functionality |
| Create Source |
Yes (hardware inputs, IP, HTML5, VLC, PowerPoint Viewer, VNC, Image and Internet Explorer)1 |
| Audio Management |
Yes (Only one audio channel can be played out at any given point of time.) |
| Source Settings2 |
Edit Source-specific Alpha Blending, Colour Keying, Hue, Saturation, Brightness, and Contrast |
| Source Touring |
Yes |
| De-interlacing Filters |
Apply Source-specific filters, including Bob, Weave, single-field, and adaptive technique |
| Preview Surface |
Yes |
| Application Control |
VLC (Volume + Play/Pause), IE (mouse and keyboard), VNC (mouse and keyboard), and PPT (previous/next slide and play/pause slide switching) |
| Video Wall Detection |
IP Address and UPnP for automatic detection |
| Video Wall Startup Control |
Ability to stop/start control and show/hide (with static background) desktop |
| Video Wall Communication Port |
Telnet (Port 23) and/or HTTPS (Port 46272) |
| Video Wall Access |
Local and/or Remote over LAN |
| Availability |
Free 21-day trial available on the Matrox Video website. USB software license available for purchase. |
