SN4741/16JS16VSP/RJ21/EUI
SmartNode VoIP Gateway, 16 FXS on RJ21-50pin, K.21 basic surge protection, 16 VoIP Calls, upgradeable to eSBC (max. 200 SIP calls), Optional SIP-TLS/SRTP, Optional Transcoding (max. 8 calls), 2x Gig Ethernet, 1x USB, 1x Console, Single External UI power (100–240 VAC), Redundant Power Supply (Optional)
Description
Features
- Up to 128 FXS - 16, 24, 32, 48, 64, 72, 96, and 128 Analog FXS ports. Long Reach FXS—10 km @ 3REN load. MWI, Caller-ID and AOC support.
- Up to 32 FXO - 16, 24, or 32 Analog FXO ports.
- Message Waiting - Message Waiting Subscription & Notify, MWI – Line reversal, high voltage and FSK support.
- Full VoIP protocol support - SIPv2, SIPv2 over TLS**, SIPv2 over IPv6, RTP security with SRTP**, T.38, fax and modem bypass, DTMF relay.
- Easy Management & Provisioning - Patton Cloud orchestrated, HTTPS zero-touch provisioning (Mutual Authentication), SNMP, command line interface and TR-069 for automated mass provisioning for efficient deployments.
- Call Quality Assessment & Monitoring - Powered by Patton Cloud; Call Quality monitoring ensures SLA is being met at the customer premise. CDR logging includes quality information, duration, Codec, etc. Accessible by Web and API (OSS/BSS integration).
- eSBC Upgrade Option - Simply by purchasing a software license, the SmartNode becomes a full blown eSBC. This capability prepares your voice network for next-generation SIP services and security.
- Optional Redundant Power - Available with fully redundant AC or DC Power
