DE7600
First Hexa Core Digital Engine
Description
CPU
8th Generation Intel® Core™
i5
i5
AiCU
-
Memory
Dual Channel
DDR4 SO-DIMM x 2
2666 MHz
32G (based on OS support)
DDR4 SO-DIMM x 2
2666 MHz
32G (based on OS support)
Graphics
Intel UHD Graphics 630
Expansion
M.2,2242 x1
M.2 2280 x1
M.2 2230 x1
M.2 2280 x1
M.2 2230 x1
Audio
Realtek HD Audio ALC269Q
LAN
Intel Gigabit Ethernet i210-AT x1
Intel Gigabit Ethernet i219LMx1"
10 / 100 / 1000 Mbps
Intel Gigabit Ethernet i219LMx1"
10 / 100 / 1000 Mbps
Storage
2.5" SATA HDD NA
M.2 SSD x 1
M.2 SSD x 1
Front Panel I/O
USB 3.1 x 2
Rear Panel I/O
DC Jack x 1
HDMI 2.0 Port x 3
USB 3.1 Port x 2
RJ45 LAN Jack x 2
Audio Set: Line-out x 1 , Mic-in x 1
Antenna Holes x 2
COM Port x 1
Extended Power Switch x 1
HDMI 2.0 Port x 3
USB 3.1 Port x 2
RJ45 LAN Jack x 2
Audio Set: Line-out x 1 , Mic-in x 1
Antenna Holes x 2
COM Port x 1
Extended Power Switch x 1
CPU Thermal Module
AOPEN Fanless design
Dimensions (W x H x D)
166 x 48 x 177 mm
Volume
1.41 L
Weight
1.74 kgs
WatchDog Timer
1 ~ 255 SEC./ min
Adapter
90W / 19V Adapter
Input Voltage
AC 100 ~ 240V
Warranty
2 Years
MTBF
50.000 hrs
Operating Temperature
-20 ~ 60ºC (-4 ~ 140ºF)
Storage Temperature
30 ~ 70°C (-22 ~ 158°F)
Relative Humidity
90% RH (60ºC non-Condensing)
