9801A5BF

Weight

1.43kg

Dimensions (W × D × H)

225 mm × 225 mm × 45 mm (without mounting brackets)

Interface

1 x 100/1000M/2.5G/5G/10G Multigigabit Ethernet, RJ-45, PoE input

1 x 1000M/10G optical port, PSFP, PoE input

1 x 10/100/1000M Ethernet, RJ-45, PoE output

Console port

1 x Management console port (RJ-45)

USB port

1 x USB 2.0 at 2.5W

PoE input

1 x 100/1000M/2.5G/5G/10G Multigigabit Ethernet, 802.3bt/at

1 x 1000M/10G optical port, 802.3bt/at

PoE output

1 x 10/100/1000M Ethernet, 802.3af

Local power supply

54V DC (center-positive circular plug) power adapter (sold separately)

Antenna type

Built-in omni-directional antenna

Antenna gain

6GHz peak gain: 5.6dBi

5GHz peak gain: 5.0dBi

2.4GHz peak gain: 4.0dBi

Note: The equivalent antenna gain is 4.1dBi in 6GHz, 3.5dBi in 5GHz and 2.8dBi in 2.4GHz

Built-in IoT module

BLE5.4

Frequencybands

2.400 to 2.4835GHz ISM

5.150 to 5.250GHz U-NII-1

5.250 to 5.350GHz U-NII-2A

5.470 to 5.725GHz U-NII-2C

5.725 to 5.850GHz U-NII-3/ISM

5.850 to 5.895 GHz U-NII-4

5.925 to 6.425GHz U-NII-5

6.425 to 6.525GHz U-NII-6

6.525 to 6.875GHz U-NII-7

6.875 to 7.125GHz U-NII-8

Note: The available bands and channels are dependent on the configured regulatory domain (country)

Modulation technology

802.11b: Direct-sequence spread spectrum (DSSS)

802.11a/g/n/ac: Orthogonal frequency-division multiplexing (OFDM)

802.11ax/be: Orthogonal frequency-division multiple access (OFDMA)

Modulation mode

11b: BPSK, QPSK, CCK

11a/g/n: BPSK, QPSK, 16QAM, 64QAM

11ac: BPSK, QPSK, 16QAM, 64QAM, 256QAM

11ax: BPSK, QPSK, 16QAM, 64QAM, 256QAM, 1024QAM

11be: BPSK, QPSK, 16QAM, 64QAM, 256QAM, 1024QAM, 4096QAM

Data rates (Mbps)

802.11b: 1, 2, 5.5, 11

802.11a/g: 6, 9, 12, 18, 24, 36, 48, 54

802.11n: 6.5 to 600 (NSS = 1 to 4, HT20 to HT40)

802.11ac: 6.5 to 6,933 (MCS0 to MCS9, NSS = 1 to 8, VHT20 to VHT160)

802.11ax: 7.3 to 9,608 (MCS0 to MCS11, NSS = 1 to 8, HE20 to HE160)

802.11be: 7.3 to 23,059 (MCS0 to MCS13, NSS = 1 to 8, EHT20 to EHT320)

Maximum transmit power

6G: 26dBm

5G: 23 dBm

2.4G: 23 dBm

Note: Transmit power is multi-chain combined power, no antenna gain is included. The actual transmit power depends on local laws and regulations

Note: To comply with spectrum regulatory requirements across different regions, the 6GHz RF (Radio Frequency) function of the device will be in a disabled state in countries/regions where the use of the 6GHz band is prohibited. Once the policy for 6GHz band usage in such countries/regions is implemented, this function can be officially activated in conjunction with future software update processes, ensuring the device operation complies with local regulations

Adjustable power granularity

Configurable in increments of 1dBm

Reset button

Restoration to factory default, AP mode control(CloudAP/FitAP)

Kensington

Kensington security slot

Installation

Wall mounting/ceiling mounting, the mounting bracket has been preinstalled on the back of the AP

Indicators (LED)

Yellow/green/blue status LEDs for different working states indicate boot loader status, association status, operating status, and fault states of the system

Temperature

Operating temperature: –10°C to +50°C

Storage temperature: –40°C to +70°C

Humidity

Operating humidity: 5% to 95% (non-condensing)

Storage humidity: 5% to 95% (non-condensing)

Protection class

IP42

Surge protection

Common Mode：4KV

Overall power consumption

Power Source

6GHz

Radio

5GHz

Radio

2.4GHz

Radio

Link speed

PSE/USB

Max PoE

power

consumption

802.3bt

4*4

2*2

2*2

10Gbps

Y

41.8W

802.3at

4*4

2*2

2*2

10Gbps

N

24.3W

802.3af

-

-

-

-

-

-

DC

4*4

2*2

2*2

10Gbps

Y

41.8W

Note: Actual power consumption may vary depending on access point usage.

Safety standards

IEC/EN 62368-1

GB 4943.1

EMC standards

EN 301 489-1

EN 301 489-3

EN 301 489-17

EN 60601-1-2

EN 55032

EN 55035

CISPR 32

CISPR 35

AS/NZS CISPR32

ICES-003 Issue 7

GB/T 9254.1

GB/T 9254.2

GB 17625.1

GB 17625.2

IEC/EN 61000-4-2

IEC/EN 61000-4-3

IEC/EN 61000-4-4

IEC/EN 61000-4-5

IEC/EN 61000-4-6

IEC/EN 61000-4-8

IEC/EN 61000-4-11

IEC/EN 61000-3-2

IEC/EN 61000-3-3

Radio standards

ETSI EN 300 328

ETSI EN 301 893, FCC Part 15E, ETSI EN 300 440

ETSI EN 303 687

RoHS standards

DIRECTIVE 2011/65/EU

(EU) 2015/863

Health standards

EN 50385:2017

EN IEC 62311:2020

MTBF (25°C)

2072861 hours
