VA-612
Wall Mount Loudspeaker
Description
Specification：
|
Model |
VA-611 |
VA-612 |
|
Power Taps @100V |
1.5W, 3W, 6W |
2.5W, 5W, 10W |
|
Power Taps @70V |
0.75W, 1.5W, 3W |
1.25W, 2.5W, 5W |
|
Impedance |
Black: COM |
Black: COM |
|
Red: 6.7KΩ / 3.3KΩ/ 1.7KΩ |
Red: 4KΩ / 2KΩ / 1KΩ |
|
|
SPL (1W/1M) |
90dB ±3dB |
91dB ±3dB |
|
Max. SPL (Rated1W/1M) |
98dB |
101dB |
|
Frequency Response (-10dB) |
90-18KHz |
90-18KHz |
|
Speaker Driver |
5" x 1 2" x 1 |
6" x 1 2" x 1 |
|
Dimension |
285 x 200 x 85mm |
345 x 240 x 100mm |
|
Weight |
1.3Kg |
1.7Kg |
|
Mounting |
Spring-clip |
Spring-clip
|
