VA-106
Ceiling Speaker
Description
Specification：
|
Model |
VA-104 |
VA-105 |
VA-106 |
|
Rated power(100V) |
1.5W, 3W, 6W |
1.5W, 3W, 6W |
3W, 6W, 9W |
|
Rated power(70V) |
0.75W, 1.5W, 3W |
0.75W, 1.5W, 3W |
1.5W, 3W, 4.5W |
|
Impedance |
Black: Com Red: 6.7KΩ/ Green: 3.3KΩ/ White: 1.7KΩ |
Black: Com Red: 6.7KΩ/ Green: 3.3KΩ/ White: 1.7KΩ |
Black: Com Red: 3.3KΩ/ Green: 1.7KΩ/ White: 1.1KΩ |
|
Sensitive(1W/1M) |
92dB |
92dB |
92dB |
|
Max sentitive(W/1M) |
99dB |
102dB |
106dB |
|
Frequency response(-10dB) |
130-16KHz |
110-18KHz |
110-18KHz |
|
Dirve unit |
4"×1 |
5"×1 |
6"×1 |
|
Cutout size |
155mm |
170mm |
220mm |
|
Dimension(mm) |
180×50mm |
200×55mm |
246×66mm |
|
Weight |
0.7kg |
0.8kg |
1kg
|
