T-2500DS
2-Channel Class-D Amplifier
Description
Specifications:
|
Model |
T-2120DS |
T-2240DS |
T-2350DS |
T-2500DS |
|
Rated Power Output |
2×120W |
2×240W |
2×350W |
2×500W |
|
Rated Output |
100V/4-16Ω |
|||
|
Input Sensitivity |
±385mV/20KΩ,Balance input |
|||
|
(impedance) |
||||
|
Overload Source Electromotive Force |
>11dB |
|||
|
Frequency Response |
80Hz~16KHz (+1, -3dB) |
|||
|
Signal-to-noise Ratio |
≥85dB |
|||
|
THD |
≤0.1% at 1KHz, 1/3 Rated power |
|||
|
Control |
Remote power control and fault indication |
|||
|
Indicator Light |
Signal, peak, protection, power |
|||
|
Protection |
Overheat, overload, short circuit |
|||
|
Cooling |
Fan forced cooling |
|||
|
Power Supply |
~220V/50Hz |
|||
|
Power Consumption |
320W |
650W |
950W |
1250W |
|
Dimension |
484×300×44mm |
|||
|
Weight |
4.4Kg |
4.5Kg |
4.6Kg |
4.7Kg |
| ≤ 0.1% at 1KHz, 1/3 rated power | ||||
