T-2120DSA

Model

T-2060DSA

T-2120DSA

T-2240DSA

Rated Power

2×60W

2×120W

2×240W

Rated Output

100V/4-16Ω

Input sensitivity(Impedance)

±385mV/20KΩ，Balanced input

Overload source

electromotive force

>11dB

Frequency Response

80Hz~16KHz (+1, -3dB)

SNR

≥85dB

THD

≤0.1% at 1KHz, 1/3 Rated Power

Control

Remote power control and fault indication

Indicator Light

Signal, peak, protection, power supply

Protection

High temperature, overload, short circuit

Cooling

Forced fan cooling

Power Supply

~220V/50Hz

Power Consumption

180W

320W

650W

Dimension

484×300×44mm

Weight

4.3Kg

4.4Kg

4.5Kg
