CAEN-7X1

The CAEN Series automation enclosures are designed to house the Crestron CLX Series lighting control modules, as well as DIN-AP4 or DIN-AP4-R control systems. Mounting DIN 4-Series™ automation processors and Cresnet® hubs to the CAEN requires a CAEN-UMP1X2-DIN-PWS. CAEN enclosures are available in an assortment of sizes, and are suitable for surface or flush wall-mount installation. Each model has been engineered to provide a clean and manageable installation and has abundant provisions for wire termination and electrical knockouts.

CAEN automation enclosures are designed to use space efficiently, supporting over a hundred possible circuits in the largest model. Both centralized and distributed configurations are possible. A single PAC2M control system installed in a central enclosure can support numerous satellite extension enclosures distributed throughout a residence or commercial facility. Interconnection of the complete network of enclosures requires just one circulating Cresnet® cable. Dozens of keypads, touch screens, wall box dimmers, shade controllers, and other peripherals can also be terminated within an enclosure, with separate compartments provided for high- and low-voltage wiring.

Crestron lighting and automation systems are completely convection cooled for silent and reliable operation. A vented front cover is included with every enclosure. All models are constructed of 16-gauge galvanized steel and are pre-drilled for mounting CLX-DIN-AP3 control systems, PAC2M control systems, CLX Series modules, CLT Series terminal blocks, power supplies, and CAEN-BLOCK terminal blocks. Additional non-CLX Series lighting modules and third-party contactors may be installed using Crestron's CAEN-UMP universal mounting plates. Grounding blocks and low-voltage partitions are included.

CAEN enclosures are also well suited for all types of Class 2 and Class 3 applications including voice and data structured wiring, security, and RF signal distribution (as permitted by applicable codes).

CAEN enclosures are UL and C-UL listed. If you require a complete UL Listed panel, Crestron offers this service through its UL Listed panel shop, providing complete in-factory system configuration and assembly.
