SMQ-1 (Last Time Buy)
The SMQ-1 is an all metal beltpack providing full duplex two-way communication.
Note: Access the Encore Power Supply Calculator to estimate power requirements for analog partyline systems.
Note: Access the Encore Power Supply Calculator to estimate power requirements for analog partyline systems.
Description
Technical
Details
- Full-duplex two-way communication
- Wide frequency response and high volume
- All metal beltpack with clip
- Noise-cancelling mic
- Mic switch and volume control
- Connects to intercom with standard mic cable
Item Code
SMQ-1
Technical
Specifications
SMQ-1
Single-ear IntercomAmplifier Type
Solid state, IC amplifiers, current-limited with reverse-polarity and short-circuit protectionSignal-to-Noise Ratio
65dBDistortion
<0.5% THD @ 1kHzMIC Pre-amp Frequency Response
200Hz - 10kHz, contoured for enhanced vocal intelligibilityMicrophone Type
Dynamic, noise-rejectingHeadphone Frequency Response
200Hz - 12kHzSound Pressure Level
110dB SPL maxPower Requirements
Talk: 10 mA average Voltage Range: 12-32V DCEnvironmental
32 - 122° F (0 - 50° C)Dimensions
Beltpack Dimensions: 1 x 3.5 x 1.5in (HxWxD)
(25 x 89 x 38mm)
