FSIC-BP19
The FSIC-BP19 is a rugged, water-resistant multi-channel beltpack that operates in the 1.9 GHz band connecting to the FreeSpeak Edge Base, Arcadia Central Station1, and Eclipse HX2 frames via E-IPA cards. The beltpack has an ergonomic design with nine programmable keys, large color screen, dedicated A & B encoders, individual level controls for C & D, a dedicated master volume control, and a built-in mic and speaker station mode. The beltpack can be deployed on the same wireless network as the existing FreeSpeak II 1.9 GHz beltpack giving users two devices to utilize.
Description
Beltpack
- Functions with FreeSpeak Edge Base, Arcadia Central Station and Eclipse HX via E-IPA cards
- Supports up to 200 beltpacks on a single system
- TFT color display (120x480)
- 4 top buttons with individual level control
- 5 additional programmable buttons
- Rotary controls on both sides and up/down level controls
- Main volume control on bottom
- BLE (Bluetooth Low Energy) Radio
- Supports Bluetooth 5.3
- Built-in mic and speaker
- Built-in flashlight
- Drop-in and USB-C charging
Connectivity
- 1.9 GHz radio frequency
- Compatible with FSII E1 and IP transceivers
- 10 beltpacks per transceiver with the FSII IPT
- Low latency audio: <35ms (70ms beltpack to beltpack)
- USB-C port for beltpack pairing and firmware updates and charging
Mechanical
- Curved shape fits to body
- IP54 rating for wet and dusty conditions
