BS410
- 2-channels of communications
- 2.4GHz license-free operation
- Supports up to 15 beltpacks in a single system
- 7kHz wideband audio
- 2-wire and 4-wire bridging on the same system
- 2-wire auto-nulling
- Lost packet concealment
- Simple to set up and configure
Technical
Specifications
Audio
Channels: 2 audio channels
Capacity: Up to 15 BP410 and/or WH410 per base station
Full-Duplex: Yes. Single-channel = 4 in simultaneous full-duplex. Dual-channel = 3 in simultaneous full-duplex. Radio Frequency Range: 2400 – 2483.5 MHz
Audio Frequency: 200 Hz – 7kHz
4-wire I/O: RJ45, 600 Ohms balanced, level adjustable, simultaneous operation with 2-wire
2-wire I/O: XLR-3M, XLR-3F, externally-switchable RTS or Clear-Com, 200Ω , level adjustable, null adjustable to 50dB attenuation, typical
Aux Input: XLR-3F with ¼” (6.35mm) combo jack, 600Ω balanced, level adjustable
Aux Output: XLR-3M, 600Ω balanced, level adjustable
Headset Connector: 4-pin mini-DIN, Electret microphone
Headset Output: 200mW into 32Ω
Antenna Type: External ½-wave dipole (R-TNC connector), RX/TX horizontal/vertical diversity
System Distortion: <2%
Communication Security: dual-slot diversity
Transmitter
Type: Frequency Hopping, Spread Spectrum (FHSS)
Transmit Power: 100mW burst
Modulation Type: Gaussian filtered FSK, TDMA
Frequency Stability: 13 ppm
Harmonics/Spurious: Exceeds FCC and ETSI specifications over temperature
Receiver
Type: Frequency Hopping, Spread Spectrum (FHSS)
RF Sensitivity: <-90dBm w 10-3 BER
Frequency Stability: 13 ppm
Distortion: <2%
Power Requirements
100 – 240V AC, 50 – 60Hz or 12 – 14V DCEnvironmental
Temperature: +32° - +122°F (0° - +50°C)Dimensions
1.75 x 19.0 x 17.13in (HxWxD)
(44 x 483 x 435mm)
