T-67240
Specifications:
|
Model |
T-6760 |
T-67120 |
T-67240 |
T-67350 |
T-67500 |
||||||||
|
Network Interface |
Standard RJ45 input |
||||||||||||
|
Transmission Speed |
100Mbps |
||||||||||||
|
Communication Protocol |
TCP/IP, UDP, IGMP (multicast) |
||||||||||||
|
Audio Format |
Mp3 |
||||||||||||
|
Audio Mode |
16-bit CD sound quality |
||||||||||||
|
Sampling Rate |
8K~48KHz |
||||||||||||
|
Output Level |
1000mV, industrial standard press-line connecting terminals |
||||||||||||
|
Output Impedance |
470Ω |
||||||||||||
|
EMC Input Sensitivity |
775mV (Unbalance) |
||||||||||||
|
AUX Input Sensitivity |
350mV (Unbalance) |
||||||||||||
|
MIC Input Sensitivity |
5mV (Unbalance) |
||||||||||||
|
Treble |
±10.5dB |
||||||||||||
|
Bass |
±10.5dB |
||||||||||||
|
Power Output |
60W |
120W |
240W |
350W |
500W |
||||||||
|
Power Consumption |
90W |
180W |
370W |
540W |
750W |
||||||||
|
Standby Power Consumption |
<3W |
||||||||||||
|
Frequency Response |
80Hz~16KHz |
||||||||||||
|
THD |
≤1% |
||||||||||||
|
S/N |
>65dB |
||||||||||||
|
Output Method |
4~16Ωconstant resistance output, 70V/100V constant resistance output |
||||||||||||
|
Protection Circuit |
DC output, over loading, over heat, short circuit protection |
||||||||||||
|
Environment Temperature |
5℃~40℃ |
||||||||||||
|
Environment Humidity |
20%~80%, Relative humidity, without condensation |
||||||||||||
|
Input Power Supply |
~220-240V 50/60Hz |
||||||||||||
|
Dimensions |
484 x 303 x 88mm |
484 x 359 x 132mm |
|||||||||||
|
Weight |
8.02Kg |
9.70Kg |
13.66Kg |
15.52Kg |
18Kg
|
||||||||
